Musical Fidelity V90-LPS MM & MC Phono Stage

The Musical Fidelity V90-LPS phono stage is a high quality design which can be used with both MM and MC cartridges (via a switch on the rear panel). The very attractive and solidly made compact case features an external 'wall wart' power supply to keep noise low, and it features a great combination of an accurate RIAA response, low noise and good overload margins, making it ideal for many entry to mid level hi-fi systems. This unit is the silver finished version.

Technical Specifications:

Performance
Input Impedance: 47kOhm (MM), 100Ohm (MC)
Input Capacitance: 100pf (MM)
Input Sensitivity: 3.0mV (MM), 400μV (MC) - for 300mV out
Total Harmonic Distortion: 0.01% (MM/MC) - @ 1kHz, 300mV out
Frequency Response: +0, –0.1dB, 20Hz to 20 kHz
Signal/Noise Ratio (A Weighted): >80dB (MM), >70dB (MC)
Input Overload Margin: 15dB (MM), 22dB (MC)
RIAA Response: +/- 0.25dB

Inputs
MM: 1 pair RCA sockets
MC: 1 pair RCA sockets

Outputs
1 pair RCA sockets

General
Dimensions (W x H x D): 170mm x 47mm x 102mm
Weight (unpacked/packed): 600g/1.1 kg
Supplied Accessories: 1x 12v 500mA DC power supply
