Technical Specifications:
Construction: Co-ax
Material: OCC
Dielectric: Microporous PTFE (Teflon™)
Screen: Braid OFC with Al Mylar,™ 100%
Capacitance: 54.50 pF/m
Inductance: 0.462 µH/m
Resistance: 0.03788 Ohms/m
Impedance: 76.1 Ohm at (1MHz)
Outside Diameter: 9.5mm
